Here's what you don't need: a separate buffer tank taking up floor space, extra piping running across your workshop, or a complicated installation that eats half a day.
The X‑Series puts the buffer tank right inside the chassis – same PSA technology, same 99% to 99.999% purity, but everything fits in one clean package. Open the crate, connect power and compressed air, and you're done. Your shop floor stays open, your installation time drops by half, and your maintenance guy has one less thing to check.
Need more nitrogen later? Add another X‑Series module – still no external tank, still no extra piping, still no headache. That's on‑site nitrogen done smart. Less clutter. Less work. Same pure gas, always ready.
Request a Quote
These models provide a typical return on investment between 6 to 24 months.
Plug-and-play system can be installed easily with minimum cost and interruption.
Compact design allows installation in spaces too small for twin tower generator systems.
| Model | Rated Outlet Flow at 116 PSI | 99.999% | 99.99% | 99.9% | 99.5% | 99% | Application |
| JBD-X1 | SCFH | 35.3 | 42.4 | 70.6 | 88.3 | 105.9 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X2 | SCFH | 70.6 | 105.9 | 176.6 | 211.9 | 247.2 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X3 | SCFH | 105.9 | 141.3 | 211.9 | 247.2 | 282.5 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X5 | SCFH | 176.6 | 247.2 | 353.1 | 423.8 | 529.7 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X8 | SCFH | 282.5 | 353.1 | 529.7 | 600.3 | 706.3 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X10 | SCFH | 353.1 | 423.8 | 565.0 | 635.7 | 777.1 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X12 | SCFH | 423.8 | 529.7 | 706.3 | 812.2 | 882.9 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X15 | SCFH | 529.7 | 706.3 | 882.9 | 953.5 | 1059.4 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X20 | SCFH | 706.3 | 882.9 | 1059.4 | 1165.4 | 1236.0 | Industrial/Electronics/Medical/Food/Petrochemical |
| JBD-X25 | SCFH | 882.9 | 1059.4 | 1236.0 | 1342.0 | 1412.6 | Industrial/Electronics/Medical/Food/Petrochemical |
| Recommended inlet air quality (ISO class) | 2.2.1 |
| Minimum inlet air quality (ISO class) | 2.4.1 |
| Minimum operating pressure | 87 psig |
| Maximum operating pressure | 116 psig |
| Burst pressure | >145 psi |
| Nitrogen pressure | ≤14.5–87 psi |
| Recommended operating temperature range | 68 to 77°F |
| Minimum/maximum operating temperature range | 41 to 122°F |
| Supply voltage | 100 - 240 V AC |
| Fuse rating | 3A 'T' |
| Frequency | 50 - 60 Hz |
| Maximum power consumption | 50W |
| IP rating | IP53 (NEMA 2) |
Configuration: Molecular sieve (CMS280), oil‑water separator, nitrogen filtration device, pneumatic components, Shanghai Chang’ai nitrogen analyzer (P860)
A nitrogen generator is a device that produces nitrogen gas (N₂) from compressed air. It uses separation methods, such as Pressure Swing Adsorption (PSA) and Membrane Technology, to remove oxygen and other gases, leaving purified nitrogen gas.
Cost savings: Long-term savings are achieved by eliminating the recurring costs of purchasing bottled nitrogen.
Convenience: Continuous on-site nitrogen generation eliminates the need for deliveries and reduces the risk of running out of nitrogen.
Customization: On-demand nitrogen generation allows you to tailor the flow and purity to your needs.
PSA (Pressure Swing Adsorption): Uses carbon molecular sieves to separate nitrogen from other gases in compressed air under varying pressure.
Membrane Technology: This technology uses selective permeable membranes to separate nitrogen from oxygen based on the size of the molecules.
